Product Information

PC Hoisting Mechanism

Item#	LTESP0000
Brand Name	SYM - Leyong
Application	Construction Usage, Workshop Usage, Mineral Area Usage
Sling Type	Cable
Power Source	Hydraulic
Installation	Jack-Up
Magnification	4
Working Frequency Hz	50, 6-50-100
Specification	All size
Tower Crane Type	Slewing Tower Crane
Main Girder Form	Single Girder
Moving Type	Fixed
Rated Single Rope Tension Kn	13, 15, 25
Rated Power of The Motor Kw	18/18/3.5, 24/24/5.5, 30, 45
Origin	China
Model NO	25PC13A, 33PC15, 24PC20, 33PC20, 40PC15, 40PC20
Rated Single Rope Tension KN	13, 15, 20, 20, 15, 20
Working Frequency Hz	50, 50,
Hoisting Speed m/min	33.5-17-3, 37.5-19-3,
Hoisting Capacity t	2.5-2.5-5, 3-6-6,
Rope capacity	360, 400,
Nominal Diameter of Wirerope mm	10, 12,

PC Hoisting Mechanism
